How to make over under voltage protection circuit
How to make over under voltage protection relay
Hi friends in this video i have made an over under voltage protection circuit this circuit can be used for both ac and dc load you can set over voltage and under voltage limit when voltage goes above the over voltage limit or goes down the under voltage limit the relay turns off hope this video would be useful please like share and subscribe
Components:
1x LM393 IC
1x BC547 TRANSISTOR
1x BC557 TRANSISTOR
2x 5K VARIABLE RESISTORS
4x 1N4007 DIODES
1x 3V ZENER DIODE
3x LEDs ( RED, GREEN AND YELLOW )
5x 1K RESISTORS
3x 4.7K RESISTORS
2x 10K RESISTORS
1x 12V RELAY
2x 2 PIN TERMINAL BLOCK
1x 3 PIN TERMINAL BLOCK
VERO BOARD
JUMPER WIRES
Circuit Diagram:
https://drive.google.com/open?id=13tV1NVMWzIM0RJAcsh8ptcI3bK8DQJQv
https://drive.google.com/open?id=1p0tbRs_I81SXufPkn-LLvi8REyxog6j5
